Chauvin Arnoux MTX 3297EX, Intrinsically Safe Multimeter (IP67)
The Chauvin Arnoux (Metrix) MTX 3297Ex is the ideal TRMS digital multimeter for your electrical measurement work in explosive Ex zones (intrinsically safe, ATEX) such as in mines, in the presence of gas, or in the presence of explosive dust.
The MTX 3297Ex is approved and certified for the highest levels of risk. It is an exceptional multimeter which meets the strictest requirements and is IP67 rated (liquid and dust-proofing).
It is a high-performance industrial multimeter compliant with the IEC 61010-2-033 standard for work on 1000 V CAT III / 600 V CAT IV electrical installations.
Key features include:
- Voltage, current and resistance measurements
- Audible continuity, diode test, etc.
- Capacitance and temperature
- TRMS AC+DC acquisition
- 60,000-count display
- Resolution from 1 μV for voltage and 0.01 μA for current
- Min, MAX, Peak+ and Peak- functions
- ΔX differential and ΔX /X relative functions
- Low-pass filter for measurement on PWM signals
- VLowZ low-impedance DC voltage in the presence of disturbance voltages
- Unrivalled ergonomics and rugged design
A stand out feature for the Chauvin Arnoux (Metrix) MTX 3297Ex is that when used with Chauvin Arnoux SX-DMM software for PC (free to download), the isolated optical communication allows real-time processing of the data, remote control of the MTX 3297Ex, upgrading and maintenance.
Competitive Edge:
Here’s a comparison with the upcoming Fluke 28 II EX:
| MTX3297 | FLUKE 28 II EX | Winner |
| LCIE 19 ATEX 3011 X | ||
| EX I M1 | I m1 | = |
| Ex II 1 G | II 2 G | MTX3297 |
| Ex II 1 D | II 2 D | MTX3297 |
| IECEx LCIE 19,0003X | ||
| Ex ia I Ma | Ex ia I Ma | = |
| Ex is IIC T4 Ga | Ex ia IIC T4 Gb | MTX3297 |
| Ex ia IIIC T135°C Da | Ex ia IIIC T135°C Db | MTX3297 |
Package Includes:
- MTX 3297Ex multimeter in a METRIX cardboard box
- Quick Start Guide (5 languages)
- User’s Manual (accessible via QR code)
- 4 x AAFR6 Lithium batteries
- Set of PVC measuring leads with 4 mm safety test probes
